DS-2CE12H0T-PIRLO

5 MP PIR Fixed Bullet Camera

5 MP PIR bullet camera
PIR detection, strobe light alarm and alarm out to warn off intruders in real time
EXIR 2.0: advanced infrared technology with 20 m IR distance
Water and dust resistant (IP67)

Артикул: 5231

Технические параметры

Available modelsDS-2CE12H0T-PIRLO(2.8mm), DS-2CE12H0T-PIRLO(3.6mm)

ПодсерияH0T-PIRL Series

Тип корпусаBullet

Разрешение5 MP

Тип объективаФиксированный

Shutter TimePAL: 1/20 s to 1/50,000 sNTSC: 1/20 s to 1/50,000 s

ИК расстояние0-20m

Focal Length & FOV91° (2.8 mm), 70° (3.6 mm), 45° (6 mm)

Тип объектива2.8 mm, 3.6 mm fixed lens

Уровень освещенностиNormal

Iris Type2.8 mm, 3.6 mm fixed lens

Уровень защитыIP67

МатериалПластик&Металл

Lens mountM12

Wide Dynamic Range (WDR)Digital WDR

Image EnhancementBLC

Image Parameters SwitchSTD/HIGH-SAT

Image SettingsBrightness, Sharpness, Mirror, Smart IR

МатериалFront cover: MetalMain body: Plastic

Dimension88.6 mm × 81.3 mm × 224.7 mm (3.49" × 3.20" × 8.85")

WeightApprox. 443 g (0.98 lb.)

LanguageEnglish

ProtectionIP67

Operating Condition‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Day & NightICR

White BalanceAuto/Manual

AGCSupport

ConsumptionMax. 3.5 W

Signal SystemPAL/NTSC

Day/Night ModeAuto/Color/BW (Black and White)

КоммуникацияHIKVISION-C

IR RangeUp to 20 m

White LightAUTO/OFF
