DS-PEA22-B(B)
Технические параметры
Available modelsDS-PEA22-B(B)
Wired network10 M/100 M Self-adaptive Ethernet port
Power supply110-220V AC
Audio input1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m1-ch 3.5 mm Audio Interface for External Audio Input
Audio output1-ch 30 W Build-in Loudspeaker1-ch 3.5 mm Audio Interface for External Audio Output
Alarm input2
Tamper-Prooftamper alarm
Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
Dimension(WxHxD)Without Bracket: 450 mm × 500 mm × 2205 mm (17.72” × 19.69” × 86.81")With Bracket: 450 mm × 500 mm × 4500 mm (17.72” × 19.69” × 177.17”)
Alarm output2
ProtocolTCP/IP, RTSP, SNMP, HIK-SIP, Standard SIP, ONVIF
BusRS-485 1, Half-duplex
Frame rate25fps
Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
Siren1, Sound Can be Configured Separately
Lamp1, Light Can be Configured Separately
PSTN1
Resolusion1920*1080
Day/night switch modeIR Cut Filter
Audio compression code rate64Kbps;16Kbps
Camera2 MP HD IR Camera
Центр загрузки
Firmware Firmware_V2.6.0_220710
